Guide: Xinli WNS6-1.25 oil/gas fired steam boiler was exported to Estonia and applied in a local alcohol plant, supplying stable high-quality steam for raw material cooking, fermentation and distillation with low-nitrogen combustion technology.
I. Project Background: Steam Demand for Alcohol Production Plant in Estonia
The customer is a professional alcohol manufacturing enterprise in Estonia, mainly engaged in the production of potato and grain-based edible alcohol, industrial ethanol and beverage spirits. It supplies products to the Estonian domestic market and Baltic European countries. The factory strictly follows EU PED safety regulations and Estonia’s strict flue gas emission and low-nitrogen environmental standards.
With production capacity upgrading, the original boiler could no longer meet technical and environmental requirements, bringing three major challenges:
The old boiler had unstable steam pressure and large fluctuation, unable to provide constant high-temperature steam required for raw material cooking, liquefaction, fermentation, distillation and concentration;
High pollutant emissions could not comply with Estonia’s low-nitrogen and clean production policies, facing rectification pressure;
Harsh cold winter climate required boiler with good thermal insulation, stable low-temperature startup and fully automatic operation to reduce manual management.
Xinli WNS6-1.25 oil/gas fired steam boiler features full automatic operation, clean combustion, low nitrogen emission and high thermal efficiency. It fully meets EU industrial safety and environmental standards. After technical verification and comparison, the customer finally selected this model to support the whole steam supply for alcohol production.
II. Customized Solution & Core Advantages
Combined with Estonia’s cold climate, EU emission limits and continuous production characteristics of alcohol plants, Xinli optimized the WNS6 oil/gas boiler for local working conditions:
Stable & Constant Steam Output: Rated evaporation 6 tons per hour, rated pressure 1.25MPa, providing stable saturated steam. Perfectly matching the continuous steam demand for potato/grain cooking, liquefaction, fermentation, distillation and concentration processes.
Low-Nitrogen Clean Combustion: Equipped with imported low-nitrogen burner and FGR flue gas recirculation technology. NOₓ emission is controlled below 100mg/Nm³, fully complying with Estonia and EU environmental protection standards.
High Thermal Efficiency & Energy Saving: Horizontal three-pass wet-back structure, high-efficiency heat transfer design, thermal efficiency over 95%. It effectively reduces gas consumption and lowers long-term operating costs for the alcohol factory.
Strong Cold Resistance & Stable Operation: Enhanced overall thermal insulation and anti-freezing design, adapting to Estonia’s severe cold winter. It realizes reliable startup and stable full-load operation under low temperature conditions.
Fully Automatic Intelligent Control: PLC intelligent control system, automatic water feeding, automatic pressure regulation, automatic ignition and operation. Few manual interventions, suitable for European factory unmanned management mode.
Compact Structure & Easy Installation: Integrated packaged boiler, small footprint, simple layout and quick on-site installation, saving workshop space and construction cycle.
High Safety & Long Service Life: Multiple safety interlock protections such as overpressure, water shortage and over-temperature. Compliant with EU PED pressure vessel standards, safe and durable for long-cycle industrial operation.
