Glass Furnace Flue Gas Waste Heat Boiler

Application:

Brewery Industry Boiler, Paper Processing Industry, Food & Beverage Industry Boiler

Capacity：3~35t/h

Efficiency：0.2~2.5Mpa

Pressure：≧70%

Fuel：Glass factories

Glass furnace flue gas waste heat boiler is an equipment with the use of 600 ℃ flue gas in glass furnace for cogeneration or steam. By using the device, the heat production system can further improve heat utilization rate of more than 70%, the high temperature waste heat resource is fully recovered in the glass furnace.

Xinli Boiler has developed the double drum exhaust type of vertical natural circulation pipe waste heat boiler and the horizontal single-pipe waste heat boiler, long life, easy maintenance, economic security, reliable. This is fully applicable for float glass furnace production line with the use of heavy oil or natural gas.

PERFORMANCE ADVANTAGES

1. Low resistance

2.This boiler employs uniform velocity and low velocity design, to reduce the power consumption.

2. Long Working Life

This boiler is U-model structure, long life and simple maintenance.

3. Low Resistance

Large diameter centralized downcomer, guarantee water circulation safe and reliable, reduce resistance.

TECHNICAL PARAMETERS

Model	Rated Evaporation Capacity (t/h)	Rated Pressure (MPa)	Steam Temperature (℃)	Feed Water Temperature (℃)
Q10/450-1.3-1.25	1.3	1.25	194	20
QC45/372-4.7-1.35/310	4.7	1.35	310	104
Q120/530-8.6-0.8	8.6	0.8	175	104
Q96/480-13.2-2.3/430	13.2	2.3	430	150
Q100/510-14-2.6/420	14	2.6	420	104
Q108/500-15-0.7	15	0.7	170	20
Q110/510-16.4-2.4/430	16.4	2.4	430	138
Q145/510-21.2-2.6/430	21.2	2.6	430	138
Note: Xinli Boiler could customize design the waste heat recovery boiler based on the actual demand
