Carbon Rotary kiln waste heat boiler

Carbon Rotary kiln waste heat boiler

Carbon rotary kiln waste heat boilers use the waste heat of the exhaust gas from carbon rotary kiln or tank carbon calciner, to produce the superheated steam for turbonator or life. After calcination, the gas has high temperature (900 to 1100 degrees Celsius), low dust content (~ 5g / Nm3), and a higher content of SOin the flue gas, based on this, the waste heat in our company solves the above problems, it emploies the vertical structure to reduce area occupation, the rectangular fin and membrance wall reduce the volume of the boiler.

4 ~ 30 t/h

Rated Evaporation Capacity

1 ~ 3.8 MPa

Working Pressure

185 ~ 450℃

Steam Temperature

Waste Heat Recovery

Application

APPLICATION INDUSTRIES

To Provide customers with safe, reliable and high-quality industry and product solutions and related services.

Central Heating Boiler

Central Heating Boiler

Central Heating Boiler

More>>
Chemical Industry Boiler

Chemical Industry Boiler

Chemical Industry Boiler

More>>
Sugar Industry Boiler

Sugar Industry Boiler

Sugar Industry Boiler

More>>
Paper Processing Industry

Paper Processing Industry

Paper Processing Industry

More>>

+

DETAILS
PRESERVATION

PERFORMANCE ADVANTAGES


1.Vertical positioned

Structure compact, compare with the traditional carbon rotary kiln waste heat boiler, occupies small areas, low investment on infrastructure, advanced structure and superior performance.

2.Steel tube economizer

High mechanical strength, shock resistance, strong adaptability to load, easy to operation.

3.Inertial separation principle

Two stage separation of gas and solid in furnace, high dust removing efficiency, and protect the environment.

TECHNICAL PARAMETERS



Model Rated Evaporation Capacity (t/h) Rated Pressure (MPa) Steam Temperature (℃) Exhaust Gas Temperature (℃)
Q11/950-4-2.5/400 4 2.5 400 190
Q11/950-4-2.5/450 4 2.5 400 170
Q11/900-4-2.5/400 4 2.5 400 155
Q15/800-5-2.6/400 5 2.6 400 180
Q15/800-5-2.6/400 5 2.6 400 180
Q26.8/900-9.8-2.5/400 9.8 2.5 400 159
Q38.2/930-15-2.5/400 15 2.5 400 148
Q50/1100-25-2.5/400 25 2.5 400 150
Q72/860-25-3.82/450 25 3.82 450 189
Note: Xinli Boiler could customize design the waste heat recovery boiler based on the actual demand
